性能特点 Characteristics of performance
本机适用范围广，卷装容量大，对原料适应性强聚乙烯丝可合股 0.2x75 股，是一种高效率，高生产捻线合股机
The product has wide applied scope and big winding capacity and strong suitability to materials. For PE, it can twine0.2 x 75 strands. lt is a twisting and stranding machine with high efficiency and output.
主要技术参数 Main technical specifications
| 操作形式 Operative form | 双面操作 Operation of double faces | 捻度范围 Scope of twist | 80-350 捻(Turns)/m |
| 锭数 Quantity of spindle | 40-72 | 钢令升降Listingmovement动程 of traveler ring(mm) | 300 |
| 锭速 Speed of spindle (rpm) | 1800-2800 | 罗拉直径 Dia.of roller (mm) | ∅57 |
| 锭距 Distance of spindle (mm) | 280-375 | 电机功率 Power of motor (kw) | 15-22 |
| 钢令直径 Dia of traveler ring (mm) | ∅204 ∅254 | 外形尺寸Overalldimensions (m) | 7.07 x 1.58 x2.27 |
| 捻向 Twisting direction | Z或S ZorS | 全机重量 Total weight (kg) | 6600 |
适用范围 Suitable scope
21 支5股~180 股纱，850D~15000D 纤维，36 tex21~70股聚乙烯的加捻或合股
21 Counts 5 strands ~ 180 strands yarn, 850D~15000D fiber, 36 tex 21~70 strands PE twisting or twine.
